28' LCG™ Steel 20 Series Car Carrier w/6k Lift/Stabilizer & Key Slots

Call for pricing
SKU: Equipment-123f6c53
Description
28' Steel Century 20 Series Low Center Gravity (LCG) Carrier; Right and Left Chain Trays; Two Front Safety Chains;
Painted in Black Acrylic Urethane;
Left and Right Side Illuminated Controls;
Federal Standard #108 LED Lighting;
Pre-Wired Electrical Junction Box; Back-Up Lights and Alarm;
7 Tie-Down Points (One in Each Front Corner, Five In The Tailboard);
Full Length Sub Frame; Full Length Slide Pads;
Bed Anti-Tilt Lockout; Roller Bed Positive Lock-Down System;
Dual 4" Bore Lift Cylinders; Dual 3.5" x 120" Extension Cylinders;
Hydraulic Pump;
Deck Specifications: Load Rating - 20,000 lbs,
Platform Floor Plate Thickness - 3/16",
Platform Width (Outside) - 102", 6" x 4" x 3/8" Angle Floor Level Bed Side - with Stake Pockets (DOES NOT Include Removable Side Rails as Standard),
Hydraulic 20,000lb. Planetary Winch,
Spring Cable Tensioner/Guide,
Winch Air Clutch Release (Drivers Side),
Cable - 9/16" x 75', Platform Main Beam - 6" I-Beam, Platform Crossmembers - 3" x 3" Cor-Ten Tube,
Crossmember Spacing 3" x 3" on 8" Center,
Subframe Rails - 5" x 3" x 1/2" H.S. Tube,
Rear Hinge Pivot - 1 Piece 2" Diameter;
Deck Height Above Chassis Frame - 7.75" Steel Deck,
8.75" Wood/Rumber Deck
Hydraulic Rear Dock Stabilizer - Includes Receiver Hitch Socket  (DOES NOT Include Receiver Hitch, Pintle Hitch, or Other Optional Hitches)
