Century 28' Steel 30 Series LCG Industrial Carrier, w/10k Wheel Lift & Galvanized Subframe

Century 28' Steel 30 Series LCG
SN: ???
10,000# Wheel Lift
Narrow Crossbar w/ Long Extenders
12" Front Hold Down Set Back
Floor Level Sides w/ 24" On Center Chain Locks
Galvanized Subframe
Dual Row Center Keyslots 4' On Center
Air Wireless Remote - Winch Function
Locking Chain Racks
Chain Binder Storage
Full Length Sub Frame with Slide Pads
Painted with Black Acrylic Urethane
Driver's & Passenger Side Chain Trays
Hydraulic Dock Stabilizer
Six Tie-Down Points (2 Front, 4 Rear)
Floor Level Sides, with Stake Pockets
Two Front Safety Chains
20,000 lb Hydraulic Winch & Cable
Winch Air Clutch Release
Bed Anti-Tilt Feature
Dual Lift Cylinders
Dual Extension Cylinders
Roller Bed Positive Lock-down
Dual Illuminated Controls
Back-Up Alarm
Hydraulic Pump 24 GPM
Mud Flaps
Federal Standard 108 Lighting

Recommended GVWR	50,000 lb — 66,000 lb
Typical Truck Frame Height	39” — 42”
Rear Wheel Type	Dual Aluminum
Recommended Rear Axle Tire Size	275/80R 22.5* 295/75R 22.5*
Minimum Distance Required between Inside Tires	49
Minimum Frame Strength RBM Each Rail	3,000,000 in/lb

Chassis Recommendations

Bed Length	30 Series Dual Wheels (‡Clear)		30/40 Series Super Single Wheels (‡Clear)
	Standard	LCB
26’	174”	192”	174”
27’	182”	204”	182”
28’ *	190”	216”	190”
29’ *	198”	228”	198”
30’ *	206”	240”	206”
